Phase Control Thyristor

Availability:

Quantity:



Inquire Add to Basket

Phase control thyristors

Product Description

Phase Control Thyristor

Features:

All Diffused Structure
Distributed Gate design
High dv/dt Capability
Low on-state Voltage
Low Switching Loss

Applications:
Traction and Transmission
HVDC
SVC
High Current Power Supply
Soft-starter
Motor Excitation
Induction Heating

Type	It(AV)	TC	Itsm@Tvjim&10ms	I²t	Vtm@It&Tj=25℃	Itm@It&Tj=25℃	Tjm	Rjc	Rc-s
Type	A	℃	A	A²s	V	A	℃	℃/W	℃/W
KP100A/1800V	320	70	3840	74000	1.60	600	125	0.0800	0.0200
KP200A/1800V	320	70	3840	74000	1.60	600	125	0.0800	0.0200
KP300A/1800V	320	70	3840	74000	1.60	600	125	0.0800	0.0200
KP320A/1800V	320	70	3840	74000	1.60	600	125	0.0800	0.0200
KP400A/1800V	400	70	4800	110000	1.60	1200	125	0.0450	0.0100
KP600A/1800V	600	65	7200	260000	1.65	1500	125	0.0400	0.0080
KP800A/1800V	800	70	9600	460000	1.60	1500	125	0.0390	0.0080
KP1000A/1800V	1000	70	12000	720000	1.45	1500	125	0.0300	0.0060
KP1200A/1800V	1200	70	14400	1000000	1.60	3000	125	0.0220	0.0050
KP1500A/1800V	1500	70	18000	1600000	1.55	3000	125	0.0180	0.0050
KP1800A/1800V	1800	70	21600	2300000	1.50	3000	125	0.0150	0.0045
KP2500A/1800V	2500	70	30000	4500000	1.45	3000	125	0.0125	0.0040
KP3000A/1800V	3000	70	36000	6500000	1.40	3000	125	0.0100	0.0030
KP4000A/1800V	4000	65	48000	11500000	1.35	3000	125	0.0080	0.0020
KP6000A/1800V	6000	65	72000	26000000	1.30	5000	125	0.0060	0.0015

Type	It(AV)	TC	Itsm@Tvjim&10ms	I²t	Vtm@It&Tj=25℃	Itm@It&Tj=25℃	Tjm	Rjc	Rc-s
Type	A	℃	A	A²s	V	A	℃	℃/W	℃/W
KP100A/2400V	500	70	7000	250000	1.80	1500	125	0.0390	0.0080
KP200A/2400V	500	70	7000	250000	1.80	1500	125	0.0390	0.0080
KP300A/2400V	500	70	7000	250000	1.80	1500	125	0.0390	0.0080
KP500A/2400V	500	70	7000	250000	1.80	1500	125	0.0390	0.0080
KP800A/2400V	800	70	11200	630000	1.80	2400	125	0.0300	0.0060
KP1000A/2400V	1000	70	14000	720000	1.80	3000	125	0.0220	0.0050
KP1200A/2400V	1200	70	14400	1000000	1.80	3000	125	0.0200	0.0050
KP1500A/2400V	1500	70	18000	1600000	1.70	3000	125	0.0150	0.0045
KP2100A/2400V	2100	70	24000	2900000	1.60	3000	125	0.0125	0.0040
KP3000A/2400V	3000	65	36000	6500000	1.45	3000	125	0.0100	0.0030
KP5700A/2400V	5700	65	68400	23000000	1.30	5000	125	0.0060	0.0015

Type	It(AV)	TC	Itsm@Tvjim&10ms	I²t	Vtm@It&Tj=25℃	Itm@It&Tj=25℃	Tjm	Rjc	Rc-s
Type	A	℃	A	A²s	V	A	℃	℃/W	℃/W
KP100A/3200V	500	70	7000	250000	2.15	1500	125	0.0390	0.0080
KP200A/3200V	500	70	7000	250000	2.15	1500	125	0.0390	0.0080
KP300A/3200V	500	70	7000	250000	2.15	1500	125	0.0390	0.0080
KP500A/3200V	500	70	7000	250000	2.15	1500	125	0.0390	0.0080
KP1000A/3200V	1000	70	12000	720000	2.10	1500	125	0.0220	0.0050
KP1200A/3200V	1200	70	14400	1000000	2.00	2500	125	0.0180	0.0050
KP1700A/3200V	1700	70	20400	21000000	1.95	3000	125	0.0150	0.0045
KP2000A/3200V	2000	70	24000	2900000	1.85	3000	125	0.0125	0.0040
KP2500A/3200V	2500	70	25200	3200000	1.75	3000	125	0.0110	0.0030
KP3700A/3200V	3700	65	44400	9900000	1.65	3000	125	0.0080	0.0020
KP4500A/3200V	4500	65	54000	15000000	1.65	5000	125	0.0060	0.0015

Type	It(AV)	TC	Itsm@Tvjim&10ms	I²t	Vtm@It&Tj=25℃	Itm@It&Tj=25℃	Tjm	Rjc	Rc-s
Type	A	℃	A	A²s	V	A	℃	℃/W	℃/W
KP100A/4200V	480	70	5760	170000	2.40	1200	125	0.0390	0.0080
KP200A/4200V	480	70	5760	170000	2.40	1200	125	0.0390	0.0080
KP300A/4200V	480	70	5760	170000	2.40	1200	125	0.0390	0.0080
KP480A/4200V	480	70	5760	170000	2.40	1200	125	0.0390	0.0080
KP1000A/4200V	1000	70	12000	720000	2.45	2500	125	0.0220	0.0050
KP1200A/4200V	1200	70	14400	1000000	2.40	3000	125	0.0160	0.0050
KP1500A/4200V	1500	70	18000	1600000	2.50	3000	125	0.0150	0.0045
KP1900A/4200V	1900	70	22800	2600000	2.30	3000	125	0.0125	0.0040
KP2100A/4200V	2100	65	24000	2900000	2.20	3000	125	0.0110	0.0030
KP3000A/4200V	3000	70	36000	6500000	1.70	3000	125	0.0080	0.0020
KP3800A/4200V	3800	70	45600	10000000	1.90	5000	125	0.0060	0.0015

Phase Control Thyristor

COMPANY PROFILE

We are a professional thyristor chip manufacturer transformed from the former state-owned enterprise.
Since 1978, we have specialized in thyristor design, production, R&D and application. We have successfully transformed into a professional development and production of solid state relays, thyristor rectifier modules. National high-tech enterprises such as AC power control conirollers and other products.
Our adherence to the principles of customer service and our commitment to competitively priced products with no compromise in quality.

COMPANY EQUIPMENT

We have our own equipment, our own warehouse,imported raw materials si,monocrystalline silicon, and aluminum profiles.

COMPANY HONOR

FAQ

Q Do you provide after-sales service?

A Of course, we offer comprehensive after-sales service. If you encounter any issues with our products during use, please feel free to contact us, and we will do our best to solve your problems. Within the warranty period, if there are any quality issues with the product, we will replace or repair it for free.
Q How can I place an order for your thyristor products?

A You can place an order by consulting our sales staff online, sending a purchase order to our email, or calling our order hotline directly.
Q Do you provide samples, and how is the charging handled?

A For low-value standard products, we can provide free samples for testing, but the customer is responsible for the shipping costs. High-value product samples come with a discount, which can be discussed on a case-by-case basis.
Q Do you have SCR Power Regulators products in stock?

A We have some conventional models in stock. For specific inventory, please consult our sales staff. For non-stock products, our delivery time is usually 15-30 days.
Q How can one determine if a thyristor is damaged?

A You can determine if a thyristor is damaged by checking if there are any anomalies in its forward and reverse blocking voltages. If so, the thyristor may be damaged. For specific products, please consult an engineer for detailed numerical reference and guidance.
