Product Description

Power modules can be divided into two categories: controllable modules and rectifier modules based on internal packaging chips; Distinguished from specific uses, it can be divided into: ordinary thyristor modules (MTC\MTX\MTK\MTA), ordinary rectifier modules (MDC), ordinary thyristors, rectifier hybrid modules (MFC), fast thyristors, rectifiers and hybrids Modules (MKC\MZC), non-insulated thyristors, rectifiers and hybrid modules (also commonly known as welding machine special modules MTG\MDG), three-phase rectifier bridge output thyristor modules (MDS), single-phase (three-phase phase) rectifier bridge module (MDQ), single-phase half-controlled bridge (three-phase fully controlled bridge) module (MTS) and Schottky module, etc.


型号 IT(AV) VRRM IRRM VFM Viso 外形
V=VRRM 50HZ,RMS
       2mA,lmin
150℃ 25℃ 25℃
TYPE @85℃ Max Max IFM Min
A V V V A V Outline
MDC/MDK/MDA 1200-2000V风冷(Air cooling)
MD*90-** 90 1200-2000 5 1.30 270 2500 Mo2-20
MD*110-** 110 1200-2000 5 1.30 330 2500
MD*160-** 160 1200-2000 5 1.30 480 2500 Mo2-34
MD*200-** 200 1200-2000 5 1.30 600 2500
MD*250-** 250 1200-2000 5 1.30 750 2500 Mo4-53
MD*300-** 300 1200-2000 5 1.30 900 2500
MD*350-** 350 1200-2000 5 1.30 1050 2500
MD*400-** 400 1200-2000 10 1.30 1200 2500 Mo4-63
MD*500-** 500 1200-2000 10 1.30 1500 2500
MD*600-** 600 1200-2000 10 1.30 1800 2500 Mo4-66
MD*800-** 800 1200-2000 10 1.45 2400 2500 Mo4-76
MD*1000-** 1000 1200-2000 10 1.45 3000 2500
MD*1200-** 1200 1200-2000 10 1.45 3000 2500 Mo4-77








MD*160-** 160 2200-3500 5 1.60 480 2500-4000 Mo2-34
MD*200-** 200 2200-3500 5 1.60 600 2500-4000 Mo4-53
MD*250-** 250 2200-3500 5 1.60 750 2500-4000
MD*300-** 300 2200-3500 5 1.60 900 2500-4000
MD*350-** 350 2200-3500 5 1.60 1050 2500-4000
MD*400-** 400 2200-3500 10 1.65 1200 2500-4000 Mo4-63
MD*500-** 500 2200-3500 10 1.70 1500 2500-4000
MD*600-** 600 2200-3500 10 1.70 1800 2500-4000 Mo4-66
MD*800-** 800 2200-3500 15 1.70 2400 2500-4000 Mo4-76
MD*1000-** 1000 2200-3500 15 1.75 3000 2500-4000
MD*1200_** 1200 2200-3500 15 1.75 3000 2500-4000 Mo4-77








MD*160-** 160 3600-4500 10 1.80 480 4000-5000 Mo2-34
MD*200-** 200 3600-4500 10 1.80 600 4000-5000 Mo4-53
MD*250-** 250 3600-4500 15 1.80 750 4000-5000
MD*300-** 300 3600-4500 15 1.80 900 4000-5000
MD*350-** 350 3600-4500 15 1.80 1050 4000-5000
MD*400-** 400 3600-4500
1.85 1200 4000-5000 Mo4-63
MD*500-** 500 3600-4500 25 1.90 1500 4000-5000
MD*600-** 600 3600-4500 35 1.90 1800 4000-5000 Mo4-66
MD*800-** 800 3600-4500 35 1.95 2400 4000-5000 Mo4-76
MD*1000-** 1000 3600-4500 35 2.0 3000 4000-5000 Mo4-77
Note: * indicates the connection mode ** indicates the module voltage
型号 IT(AV) VRRM IRRM VFM Viso 外形
V=VRRM 50HZ,RMS
       2mA,lmin
150℃ 25℃ 25℃
TYPE @85℃ Max Max IFM Min
A V V V A V Outline
MDC/MDK/MDA 1200-2000V水冷(Water cooling)
MD*400-** 400 1200-2000 10 1.35 1200 2500 Mo4-53-S
MD*500-** 500 1200-2000 10 1.35 1500 2500 Mo4-63-S
MD*600-** 600 1200-2000 10 1.35 1800 2500 Mo4-66-S
MD*800-** 800 1200-2000 10 1.50 2400 2500 Mo4-76-S
MD*1000-** 1000 1200-2000 10 1.50 3000 2500 Mo4-76-S
MD*1200-** 1200 1200-2000 10 1.50 3000 2500 Mo4-77-S
Note: * indicates the connection mode ** indicates the module voltage
